• Features

Límites de operación:
Presión: ≤2.7MPa
Velocidad: ≤23m/s
Temperatura: -30℃~+204℃

● Anillo giratorio (SiC/TC/Carbono)
● Anillo estacionario (SiC/TC)
● Sello secundario (VITÓN/Anillo encapsulado/PTFE)
● Fuelles metálicos (SUS316L/AM350/Inconel718/Titanio/Hastelloy-C/Aleación-20)
● Otras piezas (SUS304/SUS316/ Titanio/Hastelloy-C)

d (pulgadas)	d	l1	l2
1.625	0.750	1.437	1.937
1.687	0.812	1.468	1.968
1.750	0.875	1.468	1.968
1.875	1.000	1.406	2.000
2.000	1.125	1.281	2.312
2.125	1.250	1.375	2.312
2.250	1.375	1.531	2.343
2.562	1.437	1.625	2.375
2.687	1.562	1.937	2.500
2.812	1.687	1.968	2.500
2.937	1.812	1.937	2.531
3.187	1.937	1.906	2.656
3.312	2.062	1.906	2.656
3.437	2.187	1.906	2.718
3.562	2.250	2.062	2.718
3.562	2.375	2.062	2.718
3.687	2.500	2.125	2.875
3.937	2.625	2.062	3.000
4.062	2.750	2.062	3.000
4.250	2.875	2.156	3.156
4.375	3.000	2.156	3.156
4.500	3.125	2.156	3.156
4.625	3.250	2.156	3.156
4.875	3.500	2.156	3.156
5.187	3.750	2.156	3.375
5.500	4.000	2.156	3.406
5.750	4.250	2.156	3.406
6.250	4.750	2.250	3.406
