• Features

Límites de operación:
Presión: ≤2.3MPa
Velocidad: ≤23m/s
Temperatura: -30℃~200℃

● Anillo giratorio (Carbono/SiC/TC)
● Anillo estacionario (SiC/TC)
● Sello secundario (VITÓN/EPDM/Kalrez)
● Otras piezas (C-276/Duplex/316)

d1	d4		d5		d7	d8	d26	l1	l2	l3	h
(pulgadas)	min	max	min	max
24	40.0	46.0	74.6	92.0	60.3	-	104.8	30.7	37.3	23.5	12
25	41.0	49.2	74.6	92.0	60.3	-	104.8	30.7	37.3	23.5	12
28	44.0	52.4	74.6	95.3	60.3	-	108.0	30.7	37.3	23.5	12
30	46.0	55.6	77.8	98.4	63.5	-	110.0	30.7	37.3	23.5	12
32	48.0	55.6	77.8	98.4	63.5	-	110.0	30.7	37.3	23.5	12
33	49.0	55.6	77.8	98.4	63.5	-	110.0	30.7	37.3	23.5	12
35	50.8	58.7	80.9	98.4	66.7	-	110.0	30.7	37.3	23.5	12
38	57.2	63.5	85.7	114.3	71.9	-	127.0	27.7	35.6	21.6	12
40	57.2	63.5	85.7	114.3	71.9	-	127.0	27.7	35.6	21.6	12
43	60.3	63.5	85.7	114.3	71.9	-	127.0	27.7	35.6	21.6	12
45	63.5	69.8	90.5	120.7	76.7	-	133.4	27.7	35.6	21.6	12
48	66.7	69.8	90.5	120.7	76.7	-	133.4	27.7	35.6	21.6	12
50	68.0	69.8	90.5	120.7	76.7	-	133.4	27.7	35.6	21.6	12
53	71.0	76.2	100	127.0	86.0	-	139.7	29.2	35.9	21.6	12
55	73.0	84.1	111.1	130.2	93.7	-	146.0	29.2	35.9	21.6	16
58	769.2	84.1	111.1	130.2	93.7	-	146.0	29.2	35.9	21.6	16
60	79.4	90.5	117.5	136.5	100.0	-	152.4	29.2	35.9	21.6	16
63	85.7	98.4	127	161.9	109.5	-	177.8	31.8	38.1	23.5	16
65	88.9	98.4	127	161.9	109.5	-	177.8	31.8	38.1	23.5	16
70	92.1	98.4	127	161.9	109.5	-	177.8	31.8	38.1	23.5	16
75	98.5	114.3	142.9	173.0	125.4	-	190.5	31.8	38.1	23.5	16
80	101.6	114.3	142.9	173.0	125.4	-	190.5	31.8	38.1	23.5	16
85	108.0	123.7	152.4	185.7	135.0	-	203.2	31.8	38.1	23.5	16
90	114.3	127.0	171.5	195.2	150.8	127.0	215.9	31.8	47.7	19.6	20
95	117.5	130.2	171.5	195.2	150.5	127.0	215.9	31.8	47.7	19.6	20
100	123.9	139.7	188.9	207.9	168.3	136.5	228.6	31.8	47.7	19.6	20
105	130.1	149.2	189	208.0	168.3	136.5	228.6	31.8	47.7	19.6	20
110	136.5	158.8	198.4	220.6	177.8	146.1	241.3	31.8	47.7	19.6	20
115	142.9	168.3	211.1	230.2	186.6	155.6	254.0	31.8	47.7	19.6	22
120	142.9	168.3	211.1	230.2	186.6	155.6	254.0	31.8	47.7	19.6	22
